ECG Machine (Single channel) ECG-11D
Portable single-channel ECG machine designed for quick and accurate recording of cardiac activity
Lightweight and user-friendly with built-in thermal printer
Rechargeable battery and AC power supply for continuous operation
Suitable for hospitals, clinics, ambulances and routine cardiac screenings
- Intelligent simulated inflation with auto adjustment
- 3/2, 3/2+1, 3/3, 3/3+1 channel printout format
- Simultaneous 12 lead acquisition
- 4.3 inch color LCD with touch screen to display ECG waveform, setting menu and operating status
- EMG filter of 25/35/45/75/100Hz (-3dB) and CMRR of 100dB
- Automatic measurement and interpretation of ECG parameters
- Lead off detection and display on the screen
- Single channel 60s compressed record
- Rhythm analysis with R-R histogram and trend chart
- 200 exams to be stored in memory
- Able to enter patient info of ID, sex, age & weight
- Paper size of 80mm x 20m, roller type/Z-folding
- Built-in rechargeable Lithium battery supporting 100 exams
1x ECG-11D single-channel ECG machine
1x set of patient cables (12-lead)
1x ECG electrode set
1x paper roll installed
1x power adapter
1x user manual
Packed as one complete unit per box with listed accessories
Packaging Size: approximately 35 × 28 × 20 cm
