Specifications:

DEFIBRILLATOR (Biphasic)

• Defibrillator type: Manual, Synchronized, Asynchronized,
• Energy accuracy: <+1%
• Energy selection: 0, 3, 5, 7, 10, 20, 30, 50, 100, 200, 300, 360 joules (nominal at a resistance of 50)
• Charging time: Maximum 10 seconds to 360 Joules
• Standard Adult/Pediatric Paddles: Reusable external adult paddles (pediatric paddles integrated)
• Power requirements

(a) AC Power supply 100V~240V, 50Hz/60 Hz

(b) Vehicle Voltage (Option) DC 12V

Internal Battery Backup:

• Battery type: Rechargeable lead-acid battery (12V 2.0Ah X2)
• Charging time: Time-Minimum of 4 hours for full charging
• Battery charging: During AC Power Supply operation of the device.
• Charging /Low Battery Indication: Red LED
• Battery Capacity: 100% of the battery will provide 120-min monitoring; and 35 discharges at 360 joules.
• Display

(a) LCD Dimensions 7-inch
Type: High resolution true-color graphic
Resolution: 480*234

• Standard parameter & configuration: ECG RESP/SPO2/TEMP/PR/NIBP/DEFIBRILLATOR

NIBP

• Working mode: Manual/Automatic/stat (5 minutes)
• Method: Automatic oscillation
• Cuff type: standard Adult; optional Pediatric/Neonatal

SpO2

• Display: Spo2 value, pulse histogram, waveform, Pulse
• Range: 0~99%for adult, pediatric and neonatal patients
• Probe: Standard adult finger clip
• Optional pediatric Y-type clip and neonatal wrap

ECG:

• ECG lead: I, II, III, AVR, AVL, AVF, V1~V6
• S-T segment analysis: -2.0~2.0mv
• Arrhythmia analysis: Yes
• Protection: With stand 4000vAc/50Hz voltage in isolation and work against electrosurgical knife and defibrillation

RESPIRATION:

• Measurement method: Thoracic impedance

TEMPERATURE

• Measurement range 20~45°C
• Resolution 0.1°C
