Hospital Bed Five-Function (Electric)
Product Introduction
The Electric Five-Function Hospital Bed is designed for modern hospitals and long-term care facilities, offering motorized adjustment of backrest, leg section, bed height, and overall tilt. With electric control, it reduces caregiver workload while improving patient comfort and safety. The bed features a strong steel structure, medical-grade surface treatment, and reliable electric drive system for continuous clinical use.
The Electric Five-Function Hospital Bed is designed for modern hospitals and long-term care facilities, offering motorized adjustment of backrest, leg section, bed height, and overall tilt. With electric control, it reduces caregiver workload while improving patient comfort and safety. The bed features a strong steel structure, medical-grade surface treatment, and reliable electric drive system for continuous clinical use.
Specifications
Product Name: Electric Five-Function Hospital Bed
Overall Dimensions: 2100 × 960 × 475–725 mm (±10 mm)
Bed Panel Width: 900 mm (±10 mm)
Backrest Adjustment: 0°–75° (±5°)
Leg Section Adjustment: 0°–45° (±5°)
Front and Rear Tilt: ≥12° (±1°)
Maximum Load Capacity: ≤240 kg
Power Supply: AC 220V / 50Hz
Control Method: Handheld wired controller
Features
High-strength cold-rolled carbon steel frame with 30 × 60 × 1.2 mm rectangular tubes
Electrostatic powder-coated metal surface with antibacterial, antistatic, and corrosion-resistant properties
Four-section stamped steel bed panel with rounded edges and ventilation holes for air circulation
Electric motor drive system enabling smooth, stable, and quiet adjustment of all bed functions
Handheld control panel for easy operation by patients or caregivers
Detachable ABS headboard and footboard with anti-collision corners and medical record card holder
Foldable and retractable side rails for enhanced patient safety
Four 5-inch PU mute casters with individual brakes for stable positioning and easy movement
Integrated infusion stand socket
Product Name: Electric Five-Function Hospital Bed
Overall Dimensions: 2100 × 960 × 475–725 mm (±10 mm)
Bed Panel Width: 900 mm (±10 mm)
Backrest Adjustment: 0°–75° (±5°)
Leg Section Adjustment: 0°–45° (±5°)
Front and Rear Tilt: ≥12° (±1°)
Maximum Load Capacity: ≤240 kg
Power Supply: AC 220V / 50Hz
Control Method: Handheld wired controller
Features
High-strength cold-rolled carbon steel frame with 30 × 60 × 1.2 mm rectangular tubes
Electrostatic powder-coated metal surface with antibacterial, antistatic, and corrosion-resistant properties
Four-section stamped steel bed panel with rounded edges and ventilation holes for air circulation
Electric motor drive system enabling smooth, stable, and quiet adjustment of all bed functions
Handheld control panel for easy operation by patients or caregivers
Detachable ABS headboard and footboard with anti-collision corners and medical record card holder
Foldable and retractable side rails for enhanced patient safety
Four 5-inch PU mute casters with individual brakes for stable positioning and easy movement
Integrated infusion stand socket
Electric hospital bed frame
Four-section steel bed panel
Electric motor system
Handheld wired controller
ABS headboard and footboard
Side rails
Four PU brake casters
Four-section steel bed panel
Electric motor system
Handheld wired controller
ABS headboard and footboard
Side rails
Four PU brake casters
Optional 8 cm medical mattress
