Hospital Bed Five-Function (Manual)
Product Introduction
The Manual Five-Function Hospital Bed is a durable and practical nursing bed designed for hospitals and long-term care facilities. It allows manual adjustment of the back, legs, bed height, and overall tilt to support patient comfort and caregiver efficiency. The robust steel structure and medical-grade finish ensure safety, stability, and long-term use.
The Manual Five-Function Hospital Bed is a durable and practical nursing bed designed for hospitals and long-term care facilities. It allows manual adjustment of the back, legs, bed height, and overall tilt to support patient comfort and caregiver efficiency. The robust steel structure and medical-grade finish ensure safety, stability, and long-term use.
Specifications
Product Name: Manual Five-Function Hospital Bed
Overall Dimensions: 2100 × 960 × 475–725 mm (±10 mm)
Bed Panel Width: 900 mm (±10 mm)
Backrest Adjustment: 0°–75° (±5°)
Leg Section Adjustment: 0°–45° (±5°)
Front and Rear Tilt: ≥12° (±1°)
Maximum Load Capacity: ≤240 kg
Features
Cold-rolled carbon steel frame with 30 × 60 × 1.2 mm rectangular tubes
Antibacterial electrostatic powder-coated surface, antistatic and corrosion-resistant
Four-section stamped steel bed panel with rounded edges and ventilation holes
Manual ABS foldable crank system with 45# steel screw rods for smooth and quiet operation
Detachable ABS headboard and footboard with anti-collision corners and record card holder
Foldable and retractable side rails for patient safety
Four 5-inch PU mute casters with individual brakes
Integrated infusion stand socket
Product Name: Manual Five-Function Hospital Bed
Overall Dimensions: 2100 × 960 × 475–725 mm (±10 mm)
Bed Panel Width: 900 mm (±10 mm)
Backrest Adjustment: 0°–75° (±5°)
Leg Section Adjustment: 0°–45° (±5°)
Front and Rear Tilt: ≥12° (±1°)
Maximum Load Capacity: ≤240 kg
Features
Cold-rolled carbon steel frame with 30 × 60 × 1.2 mm rectangular tubes
Antibacterial electrostatic powder-coated surface, antistatic and corrosion-resistant
Four-section stamped steel bed panel with rounded edges and ventilation holes
Manual ABS foldable crank system with 45# steel screw rods for smooth and quiet operation
Detachable ABS headboard and footboard with anti-collision corners and record card holder
Foldable and retractable side rails for patient safety
Four 5-inch PU mute casters with individual brakes
Integrated infusion stand socket
Contents
Main bed frame with four-section steel bed panel
Manual crank mechanism
ABS headboard and footboard
Side rails
Four PU brake casters
Infusion stand socket
Main bed frame with four-section steel bed panel
Manual crank mechanism
ABS headboard and footboard
Side rails
Four PU brake casters
Infusion stand socket
Optional medical mattress
