Suction Pump Set Manual
Product Introduction
The Manual Suction Pump is a portable, hand-operated medical device designed for effective airway suction in emergency care, ambulances, hospitals, and home care settings. It delivers reliable suction performance without the need for electricity, making it ideal for first aid and mobile use.
Specifications
Container Volume: 300 ml
Vacuum After 1 Minute at 20 kPa: ≥15 kPa
Vacuum After 6 Times Suction: ≥20 kPa
Maximum Vacuum: ≥39.9 kPa
External Diameter of Cap (Suction Port): 17 mm
Catheter Connection Diameter: 17 mm and 9 mm
Stroke Adjustment: 50% or 100% selectable
Operating Temperature: –20°C to +50°C
Storage Temperature: –40°C to +60°C
Dimensions and Weight
Product Dimensions: 185 × 64 × 168 mm
Net Weight: 245 g
Features
Manual operation with strong and stable suction performance
Disposable 300 ml container for hygienic use
Adjustable stroke length for controlled suction
Compact and lightweight design for portability
Suitable for emergency and mobile medical applications
Contents
Manual suction pump unit
Disposable suction container (300 ml)
Packaging and Variations
Transport Package: 1 pc per bag
Specification Options: 1.5 m / 1.8 m / 2 m tubing options
