Neonate Bilirubin Phototherapy (ZHX-90P)
Product Introduction
Neonate Bilirubin Phototherapy Equipment - XHZ-90P utilizes blue LED as the primary light source, combined with yellow LED to soften the irradiated light, providing intensive phototherapy for neonatal jaundice. It features a large effective treatment area that meets AAP Guidelines for intensive phototherapy. The irradiation intensity can be adjusted between high and low levels, and the angle of the lamp module is adjustable. The radiant light is equipped with a fan cooling system to ensure low thermal radiation. It is optionally compatible with infant incubators and infant radiant warmers. The vertical height and horizontal position of the lamp module can be adjusted, and the unit includes a timer and lockable wheels for convenience and mobility.
Specifications
Power Supply: AC220V-230V/50Hz or AC110V-120V, 50/60Hz, 75VA
Light Source: Blue and yellow LED
Dominant Wavelength Range of Blue Light: 450-470nm
Clominant Wavelength Range of Yellow Light: 580-595nm
Effective Surface Area: 50cm x 25cm
Life Time of LED: 20000hrs
General Bilirubin Radiation of the Effective Surface Area (Irradiation Distance 30cm): High Irradiance Mode: 54µW/cm²/nm, Low Irradiance Mode: 30µW/cm²/nm
Uniformity of the Total Irradiance for Bilirubin: >0.4
Adjustable Range for the Height of Lamp Module: 1350mm-1680mm
Working Mode: Count up, Count down, Gear choice mode
Radiation Angle of the Phototherapy Lamp Adjustable: 0-90° from horizontal and can be locked
Built-in Timer Range: 0-99999.9
Working Noise: ≤50dB(A)
Operating Temperature Range: 18°C-35°C
Relative Humidity: 30%-75%RH
Atmospheric Pressure: 800-1050Pa
Features
The XHZ-90P provides adjustable high and low irradiation intensity to suit different treatment needs. The lamp module’s vertical and horizontal positioning, along with a radiation angle of 0-90°, allows precise targeting of neonates. The fan-cooled LED system minimizes thermal exposure while maintaining effective phototherapy. Built-in timer functions and gear selection modes enhance usability, while lockable wheels ensure mobility and stability in clinical environments. The unit is compatible with infant incubators and radiant warmers, offering flexible use in neonatal care settings.
Contents
Lamp module, mobile stand
Packaging and Variations
The product is packed as a complete unit in one carton. Carton size is 1375mm x 182mm x 230mm with a gross weight of 23Kg. Optional configurations include compatibility with infant incubators and infant radiant warmers.
