Specifications
Measurement Range (FHR1 / FHR2 optional): 50–240 bpm
Accuracy: ±2 bpm
Sweep Speed: X1, X2, X4, X8

Fetal Heart Rate (FHR)
Transducer: 9-crystal pulsed Doppler, high sensitivity
Frequency: 1.0 MHz
Probe Type: Wired / Wireless

Uterine Activity (TOCO)
Measurement Range: 0–100
Baseline Options: 0 / 5 / 10 / 15 / 20 (selectable)

Data Storage
Trend Graph Storage: 41 hours
Scoring Systems: Fischer, Krebs, ACOG

System
Operating System: Android

Printer
Type: Built-in thermal recorder
Paper Size: 110 × 100 mm
Print Modes: Real-time recording, timed recording, selectable trend printing
Print Speed: 1, 2, 3 cm/min

Network
Connectivity: Wired / Wireless, wireless terminal support

Audio
Speaker: Dual speakers
Output Power: 1W

Display
Type: 7-inch color TFT LCD, adjustable, touch screen
Resolution: 800 × 480

Power Supply
AC Input: 100–240V AC, 1.0A, 50/60Hz
Battery: Li-ion 2200mAh / 14.8V
Battery Life: Up to 4 hours continuous monitoring (FHR and TOCO)

Features
High-sensitivity Doppler transducer for accurate fetal heart rate detection
Android system for smooth operation and modern interface
Touch screen color display with adjustable viewing angle
Built-in thermal printer for instant clinical documentation
Supports wired and wireless probes and networking
Multiple international fetal scoring systems supported
