Hospital Bed Manual (2 Cranks)
A durable and adjustable hospital bed designed for patient comfort and caregiver convenience.
Equipped with two cranks for independent adjustment of the backrest and leg section.
Constructed with a sturdy steel frame and epoxy-coated finish for corrosion resistance.
Fitted with smooth-rolling wheels and locking brakes for safe mobility.
Easy to operate and maintain, ideal for general ward and home care use.
Overall size: 2100 × 960 × 500 mm
Frame material: heavy-duty steel with epoxy powder coating
Bed surface: perforated steel sheet for ventilation
Backrest adjustment: 0°–75° (manual crank)
Leg section adjustment: 0°–35° (manual crank)
Side rails: collapsible aluminum alloy rails
Castors: 125 mm swivel castors with diagonal locking system
Mattress platform height: 500 mm (fixed height)
Maximum load capacity: 250 kg
1 manual hospital bed (2 cranks)
1 mattress (optional)
1 pair collapsible side rails
1 set 125 mm swivel castors
1 user manual
Packing size: 215 × 100 × 45 cm
