Neonate Bilirubin Phototherapy (ZHX-90)
A neonatal phototherapy unit designed to treat jaundice in newborns using high-intensity blue light.
Available in both mobile and fixed models to suit different clinical environments.
Offers adjustable lamp angle and height (mobile model) for targeted treatment.
Equipped with a built-in timer to monitor therapy duration.
Energy-efficient light source options with long service life and low heat emission.
Mobile model: lamp module (with radiant light source, protective panel, and timer), lock knob, and mobile stand (with height adjustment rod, lamp column, and wheels)
Fixed model: lamp module (with radiant light source, protective panel, and timer) and lamp column
Power supply: AC220V–230V/50Hz or AC110–120V/50–60Hz
Maximum power output: 150VA (XHZ-90), 75VA (XHZ-90L)
Light source: blue fluorescent tube (XHZ-90) / LED (XHZ-90L)
Peak spectrum: 436nm (XHZ-90) / 465nm (XHZ-90L)
Highest total irradiance for bilirubin on effective surface area:
≥ 1.1 mW/cm² (XHZ-90 mobile)
≥ 0.73 mW/cm² (XHZ-90 fixed)
≥ 3.5 mW/cm² (XHZ-90L mobile)
≥ 1.7 mW/cm² (XHZ-90L fixed)
Uniformity of total irradiance for bilirubin: > 0.4
Wavelength of blue light: 420–470nm
Lifetime of LED: 5000 hrs
Lifetime of blue fluorescent tube: 2000 hrs
Adjustable lamp angle (mobile): 0–60° upward from horizontal
Height adjustment (mobile): 1350mm–1650mm
Built-in timer range: 0–9999 hrs 59 min
1 unit Neonate Bilirubin Phototherapy (ZHX-90)
1 power cable
1 user manual
Packing size: 110 × 55 × 35 cm
Net weight: 18 kg
Gross weight: 22 kg
Variations: XHZ-90 (blue fluorescent tube) / XHZ-90L (LED)
